• $AFX_HOME/esb/logs/esb.AFX-INIT.log

2017-09-20 17:06:04.117 [ERROR] com.aveksa.afx.server.init.SubmitInitializationRequestComponent:156 -
Error submitting initialization request to RSA Identity Governance and Lifecycle server!
2017-09-20 17:06:04.117 [ERROR] com.aveksa.afx.server.init.SubmitInitializationRequestComponent:162 -
Unable to establish secure (SSL) connection with RSA Identity Governance and Lifecycle server.
2017-09-20 17:06:04.118 [ERROR] com.aveksa.afx.server.init.SubmitInitializationRequestComponent:171 -
SSL certificates for RSA Identity Governance and Lifecycle server and AFX were not issued by the same
RSA Identity Governance and Lifecycle Certificate Authority(CA).
You may encounter this problem if the RSA Identity Governance and Lifecycle certificate store has been changed, but either
the RSA Identity Governance and Lifecycle server OR AFX installation hasn't been updated with the respective keystore
containing new certificate and CA entries. Please update both the RSA Identity Governance and Lifecycle server and AFX
installations with latest respective keystore available for download in the RSA Identity Governance and Lifecycle application.
2017-09-20 17:06:04.119 [ERROR] com.aveksa.afx.server.init.ServerInitializationComponent:79 -
Server initialization failed! Please correct the issue and restart AFX.
org.mule.api.transport.DispatchException: Failed to route event via endpoint:
DefaultOutboundEndpoint{endpointUri=https://sedcasod0020.emea.isn.corpintra.net:8444/aveksa/afx/initialization,
connector=HttpsConnector

• $AFX_HOME/esb/logs/mule_ee.log

ERROR 2017-09-12 16:07:44,357 [WrapperListener_start_runner] org.mule.module.launcher.DefaultArchiveDeployer:
++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
+ Failed to deploy artifact '10_AFX-INIT', see below       +
++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
org.mule.module.launcher.DeploymentInitException: CertPathBuilderException: Could not build a validated path.
	at org.mule.module.launcher.application.DefaultMuleApplication.init(DefaultMuleApplication.java:196)
	at org.mule.module.launcher.artifact.ArtifactWrapper$2.execute(ArtifactWrapper.java:62)
	at org.mule.module.launcher.artifact.ArtifactWrapper.executeWithinArtifactClassLoader(ArtifactWrapper.java:129)
	at org.mule.module.launcher.artifact.ArtifactWrapper.init(ArtifactWrapper.java:57)
	at org.mule.module.launcher.DefaultArtifactDeployer.deploy(DefaultArtifactDeployer.java:25)
	at org.mule.module.launcher.DefaultArchiveDeployer.guardedDeploy(DefaultArchiveDeployer.java:310)
	at org.mule.module.launcher.DefaultArchiveDeployer.deployArtifact(DefaultArchiveDeployer.java:330)
	at org.mule.module.launcher.DefaultArchiveDeployer.deployExplodedApp(DefaultArchiveDeployer.java:297)
	at org.mule.module.launcher.DefaultArchiveDeployer.deployExplodedArtifact(DefaultArchiveDeployer.java:108)
	at org.mule.module.launcher.DeploymentDirectoryWatcher.deployExplodedApps(DeploymentDirectoryWatcher.java:289)
	at org.mule.module.launcher.DeploymentDirectoryWatcher.start(DeploymentDirectoryWatcher.java:146)
	at org.mule.module.launcher.MuleDeploymentService.start(MuleDeploymentService.java:99)
	at org.mule.module.launcher.MuleContainer.start(MuleContainer.java:152)
	at sun.reflect.NativeMethodAccessorImpl.invoke0(Native Method)
	at sun.reflect.NativeMethodAccessorImpl.invoke(NativeMethodAccessorImpl.java:57)
	at sun.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43)
	at java.lang.reflect.Method.invoke(Method.java:606)
	at org.mule.module.reboot.MuleContainerWrapper.start(MuleContainerWrapper.java:52)
	at org.tanukisoftware.wrapper.WrapperManager$11.run(WrapperManager.java:4048)
Caused by: org.mule.api.config.ConfigurationException:
Error creating bean with name 'serverInitialization' defined in URL
[file:/home/afxusr/AFX/esb/apps/10_AFX-INIT/mule-config.xml]:
Instantiation of bean failed; nested exception is org.springframework.beans.BeanInstantiationException:
Could not instantiate bean class [com.aveksa.afx.server.init.ServerInitializationComponent]:
Constructor threw exception; nested exception is org.mule.api.lifecycle.InitialisationException:
Server initialization failed! Please correct the issue and restart AFX.

• $AFX_HOME/esb/logs/esb.AFX-MAIN.log

2017-09-12 16:07:45.588 [ERROR] org.mule.module.launcher.application.DefaultMuleApplication:361 -
null java.lang.IllegalArgumentException: Could not resolve placeholder 'afx.server.activemq.password'
in string value "${afx.server.activemq.password}"

1. In the WebSphere console, navigate to Security > SSL certificate and key management > SSL configurations.

2. Select the associated Aveksa SSL configuration.

3. Under Additional Properties, select Quality of Protection (QoP) settings.

4. Under Client authentication, select Required.
5. Under Protocol, select TLSv1.2.
6. Click OK to save the changes.

7. Restart WebSphere.
